Key Features :
-
Voltage and frequency protection relay.
-
For transformers and electrical machines in HV, MV, and LV systems.
-
Auxiliary supply 24–230 V DC/AC.
-
5 voltage channels for conventional VTs; measures up to 1,000 V direct on LV line.
-
Metallic housing with high EMC and wide operating temperature range.
-
Protection against decoupling, load shedding, and Loss of Main (islanding) via voltage, frequency, and ROCOF method.
-
Circuit breaker (52) and recloser (79) signaling/control.
-
Front navigation keypad: 7 keys (including RESET), 6 programmable hot keys for CB control, recloser block/unblock, local/remote mode; 3 configurable control LEDs; 8 programmable alarm LEDs.
-
Communication: front micro-USB; rear serial port (IEC60870-5-103, Modbus RTU, DNP3.0 selectable); rear Ethernet port (Modbus TCP/IP, DNP3.0 TCP/IP, IEC60870-5-104, IEC61850 selectable) + SNTP + Web Server.
-
Optional Wi-Fi and IRIG-B synchronization.
-
Configurable I/O: 8 inputs + 7 outputs or 11 inputs + 5 outputs (model dependent).
- Non-volatile RAM stores up to 3072 events and DFR; internal RTC; configurable pre/post-fault recording options (5, 25, 50, 100 records) in data and COMTRADE formats.
- Oscillography: 9 analogue + up to 96 digital channels; downloadable via SICom software in COMTRADE format.
