Key Features :

• Self-powered via three /1 CTs (<2VA).
• Auxiliary supply: 24–230 V AC/DC, USB (with KITCOM) or power bank.
• Optional internal battery (20-year lifetime) for commissioning.
• Very low start-up currents: 75 mA (3-phase), 160 mA (1-phase).
• Metallic enclosure, high EMC, wide temperature range.
• Trip test menu available before system energization.
• Four configurable LEDs and self-diagnostics (WATCHDOG).
• Front USB and optional RS485 (Modbus RTU/ DNP3.0) communication ports.
• Trip output (24 Vdc – 135 mJ), 3 configurable inputs,3 outputs.
• Records load data (168 circular records,configurable intervals).
• Stores 1024 events, 20 fault reports, 10 oscillographic records (COMTRADE format) with internal RTC.
• Oscillography downloadable via SICom software.
• No external batteries needed, lower operation Cost.
• Compact and lightweight, easy installation and transport.
